In the intricate dance of forces that define railway operations—where dynamic loads meet relentless vibration—elasticity is not a luxury, it’s a necessity. Enter the SKL14 Rail Clip, a precision-engineered spring component critical to maintaining constant toe load, ensuring rail stability, and absorbing energy in today’s high-performance track systems.
Why the SKL14 Clip is Non-Negotiable for Track Integrity:
Constant Toe Load Maintenance: Exerts uniform pressure on the rail foot, preventing loosening under vibration or thermal expansion.
Fatigue Resistance: Engineered for 3+ million load cycles, far exceeding conventional clips in high-stress corridors.
Vibration & Impact Absorption: Reduces force transmission to sleepers and ballast, cutting maintenance costs by ≤30%.
Corrosion Defense: Optional advanced coatings (Dacromet®, Geomet®, Zn-Ni) resist salt, abrasion, and chemical exposure.
Quick Installation/Replacement: Designed for efficient maintenance with standard clip applicators.
Engineering Excellence: What Sets the SKL14 Apart
1. Precision Material Science & Manufacturing:
Cold-Formed Spring Steel: High-carbon steel (e.g., 60Si7, EN 10270-1) cold-formed to enhance grain structure and fatigue strength.
Optimized Heat Treatment: Stress-relieving and tempering processes achieve HRC 44–50 hardness for ideal elasticity-to-strength ratio.
Surface Integrity: Shot-peened finish eliminates micro-cracks, boosting fatigue life by ≥25% vs. non-treated alternatives.
| Diameter | φ13 |
|---|---|
| Weight | 0.508kg/pc |
| Material | 60Si2Cr, 38Si7, etc |
| Hardness | 42-47HRC |
| Surface Treatment | Plain Oiled, Oxygen Black, Zinc Plated, Hot Dip Galvanized, Dacro coating, Color Painting |
2.Corrosion Protection for Harsh Environments:
| Coating Type | Protection Life | Key Applications |
|---|---|---|
| Dacromet®/Geomet® | 1,000+ hrs salt spray | Coastal, tunnels, de-iced tracks |
| Zinc-Nickel (Zn-Ni) | 720–1,000 hrs salt spray | Heavy haul, industrial zones |
| Epoxy-Polyester | Chemical/abrasion resistance | Mining, desert environments |
3.Certified Quality & Traceability:
Batch Testing: 100% dimensional checks + mechanical testing (hardness, deflection, toe load).
Fatigue Validation: 3 million cycle testing per EN 13481-5 + UIC 864-6.
Full Compliance: Meets DB TL 918 0113, EN 13481-1, UIC 864, and Network Rail NR/L2/TRK/2101.
If you have any other products you would like to consult, please feel free to contact us!
